D + H SDS 2-DU-24V

By: Joseph

Brand: D+H | Manufacturer Part numbers:  SDS 2-DU-24V

This product is suitable for:

  • Roof Skylights
Specifications at a glance:

Power Supply: 24 V DC / ±15 % / 4 A
Nominal Locking Force: 2200 N
Protection Class: IP64

Colours Available:

Available in Anodized Aluminium
SAA


Bracket Options:
Options listed in Download Pdf below.
Get in touch for help picking the right brackets for your window.

NOT SURE IF THIS IS EXACTLY RIGHT?
Call 01702 826267 to order or for advice
CALL TO ORDER NOW
Next Day Delivery on 100s of Products
EXPERT ADVICE
Free for Trade & Public

Don’t worry call us on our product support line and our experts will give you free advice and guidance
to find the correct product for your application: 01702 826267

Description

D+H SDS 2 skylight system consists of a drive unit and a skylight-specific installation set. A force of pressure of 3000 N and a running speed of 11.1 mm/s make this system the optimal solution for opening and closing skylights.

For opening and closing skylights for ventilation and smoke extraction applications
System consisting of drive unit and skylight‑specific installation set
With integrated BSY+ motor and synchronised electronics controlled via microprocessor
Service life inspected with at least 20000 opening cycles for ventilation and an additional 1000 opening cycles for smoke extraction in accordance with EN 12101‑2
Optimal aerodynamic values by quick opening to 172°
Power transmission structurally optimised, therefore minimum strain on ventilator frame and hinges
High type of protection for drive unit; can therefore also be used under difficult ambient conditions
Quick installation and easy handling thanks to modules pre‑installed at the factory
Installation sets available for many skylights

Buy Now

Free Live Product Support - help finding window opener products

Order Now by Phone

The range of manual and electric window openers is vast and choosing the right solution depends on your needs. Our website carries just a sample of the most popular products we sell, but by no means covers everything we stock or can supply. It is always best to call us and we will help you confirm if it is the correct product for your exact needs.

To Order Dial: 01702 826 267

Brand

Product Applications

This product is suitable for:

  • Roof & Skylight windows

Technical Details

Model:

SDS 2-DU-24V

Power Supply:

24 V DC / ±15 % / 4 A

Force of pressure:

3000 N

Tensile force:

3000 N

Nominal locking force:”2px 2px 2px 2px” class=”one_third_grey”]
2200 N

OPEN running speed:

7.1 mm/s

CLOSED running speed:

7.1 mm/s

Protection:

IP 64

Wind load class:

1500 Pa

Snow load class:

500 Pa

Fire resistance:

B300 (30 min / 300 °C)

Connection:

2.5 m silicone cable

Download PDF's

SDS 2-DU-24V Instructions
