D + H SDS 3 1000-5

By: Joseph

Brand: D+H | Manufacturer Part numbers:  SDS 3-1000-5

This product is suitable for:

  • Roof Skylights
Specifications at a glance:

Power Supply: 230 V AC / +10 % … -15 % / 147 VA
Nominal Locking Force: 3400 N
Protection Class: IP54

Colours Available:

Available in Anodized Aluminium
SAA


Bracket Options:
Options listed in Download Pdf below.
Get in touch for help picking the right brackets for your window.

NOT SURE IF THIS IS EXACTLY RIGHT?
Call 01702 826267 to order or for advice
CALL TO ORDER NOW
Next Day Delivery on 100s of Products
EXPERT ADVICE
Free for Trade & Public

Don’t worry call us on our product support line and our experts will give you free advice and guidance
to find the correct product for your application: 01702 826267

Description

The sky’s the limit: With an opening angle of up to 170° and a force of up to 2200 N, this skylight system is virtually unbeatable. With continuous adjustment to all skylights from 800-1200 mm and developed for use in accordance with EN 12101-2 including emergency unlocking. Extremely quiet operating noise and available in 24 and 230 volt versions.

For opening and closing skylights for ventilation and smoke extraction applications up to an opening angle of 170°
Outstandingly quiet drive for convenient daily ventilation
Up to 2200 N of max. system load (skylight incl. snow load) thanks to optional power pack
Maximum coupling weight of 90 kg (max. opening angle of 120°)
Electronic system for SA and SZ signalling that can have modules added to it, BSY+ (synchronous operation of 2 systems) and interface to the ACB Gateway
Maximum opening angle can be adjusted using D+H SCS software
SDS 3-0800 basic system for flexible use in skylights at an installation clearance dimension of 800 mm – 999 mm
SDS 3-1000 basic system for flexible use in a skylight at an installation clearance dimension of 1000 mm – 1200 mm
Emergency unlocking already integrated in basic system
System that can be expanded using modules with customer-specific installation sets and dimensions (up to 2 m)
Easy installation thanks to pre-installation of the brackets and convenient mounting from above
Mechanical locking mechanism for increased wind loads and burglary protection incl. emergency unlocking (optional)

Buy Now

Free Live Product Support - help finding window opener products

Order Now by Phone

The range of manual and electric window openers is vast and choosing the right solution depends on your needs. Our website carries just a sample of the most popular products we sell, but by no means covers everything we stock or can supply. It is always best to call us and we will help you confirm if it is the correct product for your exact needs.

To Order Dial: 01702 826 267

Brand

Product Applications

This product is suitable for:

  • Roof & Skylight windows

Technical Details

Model:

SDS 3 1000-5

Power Supply:

230 V AC / +10 % … -15 % / 147 VA

Nominal Locking Force:

3400 N

OPEN running speed:

60 s

CLOSED running speed:

60 s

Wind load class:

1500 Pa

Snow load class:

750 Pa

Protection:

IP 54

Temperature range:

-5 °C … +75 °C

Fire resistance:

B300 (30 min / 300 °C)

Connection:

Electronic box, screw terminals

W x H x D:

423 x 25 x 25 mm

Max. OPENING force incl. snow load:

2200 N

Max. CLOSING force:

500 N

Nominal locking force on the lift arm:

3400 N
