Aumuller Window Louvre Drive LLA16 S12 24 V DC
Window Louvre Drive LLA. Modern SHEV systems and ventilation systems are complex high-tech systems. But louvre drives from AUMÜLLER offer more than technical perfection and outstanding functionality. They give you and your project freedom. Whether technology, appearance or equipment – intelligent systems from AUMÜLLER will meet your individual requirements without compromise.


  • Reliable Function: through high-quality, durable, wear-free materials and inherently safe construction.
  • Fast Assembly: direct fixing points without brackets, various driver adapters for universal use.
  • Self-learning: automatic configuration of synchronous operation and sequence control in the multi-drive system via external M-COM module.

Self-learning stroke detection, convenient installation and user-friendly emergency cut-off function: louvre drives from AUMÜLLER meet the precise requirements of modern slat-based window systems. How does it work?
Visually appealing: the paint finish on the drive housing in the colour of the louvre window naturally integrates into the overall design of the facade.
Smart: microprocessor controlled load dependant cut-off electronics enable synchronous operation in multi-drive systems without additional modules and project-specific programming.
Safe: An emergency cut-off programme works quickly and easily, minimising material damage in the event of a malfunction.

Additional information




Product Applications

This product is suitable for:

  • Dome & Skylight windows
  • Top & bottom hung windows
  • Pivoting windows

Technical Details

LLA16 S12 24 V DC
Switch-off electronics:
S12 – integrated, intelligent control electronics
Rated Voltage:
24 V DC
Cut-Off Current:
1.2 A
60 – 200 mm; programmable
1600 / 1600 N;programmable
Speed (Open / Close):
4.0 / 4.0 mm/s; programmable
Housing (W x H x L):
anodised aluminium, 35 x 35 mm, length stroke dependent; plastic end caps
Connection Cable:
halogen free, grey, 2×0.75 mm², length 1 m
Protection Rating:
IP 40

Download PDF's

LLA16 S12 24 V DC Instructions

Assembly Instructions
