Aumuller SP8 S2 24 V DC (Z)
Spindle drive SP from AUMÜLLER. Ist functional and shapely exterior blends seamlessly into any structure. The power unit offers a drive force of 800 N and a guaranteed straight-forward installation thanks to the easy-to-install fastening via clamping blocks.

  • Large Bandwidth: applicable for natural ventilation and SHEV, in roofs and facades.
  • Reliable Function: through high-quality, durable, wear-free materials and inherently safe construction.
  • Fast Assembly: universally applicable, various mounting options, flexible cabling.

Make your windows smart and safe. SP-Spindle drives guarantee full control when opening and closing of roof windows and skylights. With 230 V, the SP model is the ideal ventilation drive for pneumatic SHEV skylights

Additional information




Product Applications

This product is suitable for:

  • Dome & Skylight windows
  • Top & bottom hung windows
  • Pivoting windows

Technical Details

SP8 S2 24 V DC (Z)
Switch-off electronics:
S2 – integrated load-dependant cut-off switch in OPEN/CLOSE direction
Rated Voltage:
24 V DC
Cut-Off Current:
1.0 A
100 – 750 mm; mechanically shortenable
Force (Push / Pull):
800 – 350 / 800 N; dependant on mounting
Speed (open / closed):
7.0 / 7.0 mm/s
Housing (W x H x L):
7.0 / 7.0 mm/s
Connection Cable:
halogen free, grey, 2×0.75 mm², length 1 m; “Z”: 4×0.75 mm²
Protection Rating:
IP 54 (option: IP 65)

Download PDF's

Aumuller SP8 S2 24 V DC (Z) Instructions

Assembly Instructions
