KSA S12 24 V DC (Z)
Brand: Aumuller | Manufacturer Part numbers: KSA S12 24 V DC
This product is suitable for:
- Dome & Skylight windows
- Top & bottom hung windows
- Pivoting windows
Specifications at a glance:
Thrust & Traction force: 400 – 50 / 400 N; stroke dependant, programmable from 5.0 mm/s
Max Strokes: 50 – 1000 mm; programmable
Voltage supply: 24 V DC
Protection Class: IP 32
Colours Available:
Grey |
Key Specs
| Stroke (mm) | Programmable, 200, 1500 |
|---|---|
| Max Force (N) | 600 |
| Supply Voltage | 24Vdc |
| Max Current (amps) | 1.2 |
| Max Speed (mm/s) | 13.5 |
| Window Types | Bottom Hung, Centre Pivot, Rooflight, Side Hung, Skylight, Top Hung |
| IP Rating | IP30 |
| Colour/Finish | Silver |
| Application | Natural Ventilation |
Available Colours
Suitable Applications
Aumuller KSA S12 24 V DC Instructions
