Description
Our compact energy sources: use our compact control units to control 24 V DC electromotive window operators. Open and close windows for SHEV or controlled natural ventilation in small to medium sized building sections such as stairwells.
Ready to use, when, where and how you want. The area of application adapts to your wishes and ranges from simple stairwells to complex smoke and heat ventilation systems with data-bus network technology and decentralised power supply.
Building Automation in Perfection. Use all functions of modern, future-orientated building automation.
Our solutions help you reduce the amount of wiring needed and minimize installation costs.
Both smoke and heat exhaust ventilation or natural ventilation: our control units offer the best solution for your electric window opening.
Additional information
| Manufacturer |
|---|
Technical Details
| EMB7300 2.5A 0101 | EMB7300 5A 0101 | EMB7300 10A 0101 | |
|---|---|---|---|
| Zones | 1x SHEV & 1xVentilation Group | 1x SHEV & 1xVentilation Group | 1x SHEV & 1xVentilation Group |
| Operating Voltage | 230Vac (195-253Vac, 50/60 Hz) | 230Vac (195-253Vac, 50/60 Hz) | 230Vac (195-253Vac, 50/60 Hz) |
| Output Voltage | 24Vdc | 24 Vdc | 24Vdc |
| Output Current | 2.5A | 5A | 10A |
| Ambient Temperature | -5°C … +40°C | -5°C … +40°C | -5°C … +40°C |
| Ingress Protection | IP30 | IP30 | IP30; IP54 w/optional mount and brackets |
| Housing | Surface Mounted, Steel Plate | Surface Mounted, Steel Plate | Surface Mounted, Steel Plate |
| Dimensions (WxHxD) | 225 x 285 x 122 mm | 225 x 285 x 122 mm | 400 x 300 x 150 mm |
| Prepared for Emergency Batteries | 2 x 12V / 2.3Ah | 2x 12V / 2.3Ah | 2x 12V / 7Ah |
| Connection Terminals | 1.5mm2 / Drives: 4mm2 (rigid) | 1.5mm2 / Drives: 4mm2 (rigid) | 1.5mm2 / Drives: 4mm2 (rigid) |
EMB7300 2.5 A 0101 Instructions
