Product Information
Description
Window Master WET 200
KNX temperature and lux sensor with GPS receiver
- temperature is measured between -30 – +55°C
- light is meassured between 1 – 22.000 lux
- GPS data received: geographical possition (LAT/LONG), angle of solar radiation during the day, sunrise / sunset times
- the measurements are sent directly via the KNX bus
Natural ventilation
The product is suitable for comfort ventilation to ensure that the building’s users enjoy a comfortable indoor climate
KNX certified
The product is KNX certified and supports this BUS communication
Outdoor sensor used for measuring temperature and light with GPS receiver.
The measurements are sent directly via the KNX bus.
Additional information
| Manufacturer |
|---|
Brand
Window Master
Technical Details
Model:
WET 200
Current consumption:
approx. 10mA
Power supply:
KNX bus
Operating conditions:
-30°C – +55°C
Material:
self extinguishing thermoplastic
Size:
sensor: 75 x 31 x 65 (W x H x D)
bracket: 52 x 38 x 57 (W x H x D)
bracket: 52 x 38 x 57 (W x H x D)
Temperature, range of meassurement:
-30°C – +55°C
Light, range of meassurement:
1 – 22.000 lux
Window Master WET 200 installation
