Product Information

Description

Topp TF23R & TF33R Control Units
Control & Power Units
Control and feeding unit with 2 outputs at 24V and 1 output at 230V, max. 1,5A each.
Provided with remote control receiver, either at 433,92 MHz or infra-red.
Input for one RW wind sensor with adjustable speed threshold via trimmer.

TF33R Control and feeding unit with 2 outputs at 24V and 1 output at 230V, max. 1,5A each. Provided with remote control receiver, either at 433,92 MHz or infra-red. Input for one RW wind sensor with adjustable speed threshold via trimmer.
Possibility to operate two RDC 12V rain sensors simultaneously. A blue LED indicates the control unit and the remote control status. All functions (rain sensor exclusion, manual operation, thermostat connection, etc.) can be set out via dipswitch. CE marked device.

Additional information

Manufacturer

Brand

Topp
Topp

Technical Details

Model:
 TF23R
TF33R
Power voltage:
230V ~ 50Hz
230V ~ 50Hz
Output Voltage:
24V-230V
24V-230V
Max power consumption:
32 W
32 W
Pre-set for:
wind sensor, rain detector, push button
wind sensor, rain detector, push button
Absorbed current:
0,22 A
0,75 A
Operating temperature:
– 5°C + 50°C
– 5°C + 50°C
Protection Class:
  IP 30
IP30
Dimensions:
150x80x55mm
150x80x28mm
Connectable actuators C20:
3
3
Connectable actuators C20 TANDEM:
Connectable actuators C30:
Connectable actuators C40:
Connectable actuators C60:
3
3
Connectable actuators ACK4:
Connectable actuators C130:
3
3
Connectable actuators C160:
Connectable actuators C240:
Connectable actuators C260:
  –
Connectable actuators S80:
Connectable actuators T50:

Download PDF's

TOPP Control units TF RR instructions
