D+H FRA 11-BSY+ Locking Drive

Call us for latest pricing

Brand: D+H | Manufacturer Part numbers: FRA 11-BSY+, FRA-BSY+

This product is suitable for:

  • Roof & Skylight windows
  • Top & bottom hung windows
  • Conservatory Ventialtion
Specifications at a glance:

Power Supply: 24 V DC / ?15 % / 1 A

Force: 3000 N

Stroke: 500 – 1500 mm

Nominal locking force: Max. 2800 N

Protection Class: IP64

Colours Available:

Available in Silver

Silver

D+H FRA 11-BSY+
Safety first: Your windows lock automatically thanks to this drive. The FRA 11-BSY+ replaces the handles on your window sashes and provides an increased level of burglary protection.

With motor electronics controlled via microprocessor for communication and sequence control of connected BSY+ and PLP window drives for opening windows
To be used in conjunction with an internal chamber gearbox and 43 mm mounting distance
Can be combined with any D+H drive with BSY+ technology
BRV (for PLP) or VP (for BSY+ / ACB) option required for connected window drive
Up to 4 FRA 11‑BSY+ drives on one window possible
Position display for the locking mechanism
LED status display for the drive
Automatic locking mechanism for the window
Increased burglary protection

Brand

Product Applications

This product is suitable for:

  • Roof & Skylight windows
  • Top & bottom hung windows
  • Conservatory Ventialtion

Technical Details

Model:

FRA 11-BSY+
Power Supply:

24 V DC / ±15 % / 1 A
Torque:

10 Nm *
Rotation angle:

90° / 180 °
Emission sound pressure level:

LpA ≤ 70 dB(A)
Temperature range:

-5 °C … +75 °C
Fire resistance:

B300 (30 min / 300 °C)
Housing:

Polyamide
Surface:

Painted
Protection:

IP 40
Fire Resistance:

B300 (30 min / 300 °C)
Connection:

2.5m silicone cable
Dimension:

W 43 x H 200 x D 43 mm
