D + H DDS 54

By: Joseph

Brand: D+H | Manufacturer Part numbers:  DDS 54/500, DDS-PLP

This product is suitable for:

  • Roof & Skylight windows
  • Top & bottom hung windows
  • Conservatory Ventialtion
Specifications at a glance:

Power Supply: 24 V DC / ±15 % / 1 A
Force: 500 N
Protection Class: IP32

Colours Available:

Available in White
White


Bracket Options:
Options listed in Download Pdf below.
Get in touch for help picking the right brackets for your window.

NOT SURE IF THIS IS EXACTLY RIGHT?
Call 01702 826267 to order or for advice
CALL TO ORDER NOW
Next Day Delivery on 100s of Products
EXPERT ADVICE
Free for Trade & Public

Don’t worry call us on our product support line and our experts will give you free advice and guidance
to find the correct product for your application: 01702 826267

Description

In the event of a building fire, you need to provide smoke extraction in the roof area and supply fresh air at the lower section of the wall. The DDS 54 opens your doors a maximum of 90° using a force of pressure of 500 N, making your escape routes accessible as well.

For opening single‑leaf doors up to 90°
With motor electronics controlled via microprocessor
High force of pressure due to special chain stabilisation
Control output for on‑site electronic door release
Guarantees the necessary supply air and open escape routes
The door remains operable by hand
Automatic motor lock, Ikon or Ehem, can be combined
Programmable drive functions and different drive parameters
Additional passive and active anti‑trap protection system for the main closing edges
Bracket set included

Buy Now

Free Live Product Support - help finding window opener products

Order Now by Phone

The range of manual and electric window openers is vast and choosing the right solution depends on your needs. Our website carries just a sample of the most popular products we sell, but by no means covers everything we stock or can supply. It is always best to call us and we will help you confirm if it is the correct product for your exact needs.

To Order Dial: 01702 826 267

Brand

Product Applications

This product is suitable for:

  • Roof & Skylight windows
  • Top & bottom hung windows
  • Conservatory Ventialtion

Technical Details

Model:

DDS 54

Power Supply:

24 V DC / ±15 % / 1 A

Force of pressure:

500 N

Tensile force:

500 N

OPEN running speed:

11.8 mm/s

CLOSED running speed:

11.8 mm/s

Emission sound pressure level:

LpA ≤ 70 dB(A)

Protection:

IP 32

Emission sound pressure level:

LpA ≤ 70 dB(A)

Temperature range:

-5 °C … +75 °C *

Fire resistance:

B300 (30 min / 300 °C)

Housing:

Aluminium

Connection:

2.5 m silicone cable

W x H x D:

522 x 40 x 80 mm

Download PDF's

DDS 54 Instructions
