Product Information
Description
Aumuller SP8-Z S2 230 V AC
Spindle drive SP from AUMÜLLER. Ist functional and shapely exterior blends seamlessly into any structure. The power unit offers a drive force of 800 N and a guaranteed straight-forward installation thanks to the easy-to-install fastening via clamping blocks.
- Large Bandwidth: applicable for natural ventilation and SHEV, in roofs and facades.
- Reliable Function: through high-quality, durable, wear-free materials and inherently safe construction.
- Fast Assembly: universally applicable, various mounting options, flexible cabling.
Make your windows smart and safe. SP-Spindle drives guarantee full control when opening and closing of roof windows and skylights. With 230 V, the SP model is the ideal ventilation drive for pneumatic SHEV skylights
Additional information
| Manufacturer |
|---|
Brand
Aumuller
Product Applications
|
This product is suitable for:
|
Technical Details
Model:
SP8-Z S2 230 V AC
Switch-off electronics:
S2 – integrated load dependant electronics in OPEN/CLOSE direction
Rated Voltage:
230 V AC
Cut-Off Current:
0.2 A
Stroke:
300 – 750 mm
Force (Push / Pull):
800 – 350 / 800 N; dependant on mounting
Speed (open / closed):
7.0 / 7.0 mm/s
Housing (W x H x L):
anodised aluminium, 76 x 43 mm, length stroke dependant
Connection Cable:
halogen free, grey, 6×0.72 mm², length 1 m
Protection Rating:
IP 54 (option: IP 65)
Aumuller SP8-Z S2 230 V AC Instructions
